Flexible Wires & Single Core Flexible Cables
Accord Single Core Flexible Wires and Twin Parallel Flexible Cables are designed for dynamic domestic and industrial installations. Insulated with high-grade dielectric PVC over bunched annealed bare copper strands, these wires deliver excellent conductivity, high current capability, and exceptional flexibility. Their smooth, high-retention PVC skin makes routing through conduits and wiring boards simple and quick. They are highly resistant to oil, acids, moisture, and elevated temperatures, ensuring stable electrical loads in household appliances, control cabinets, and commercial fixtures.
Key Features & Advantages
Excellent Bending & Flexibility
Constructed with fine-drawn bare copper strands, permitting easy routing and wiring in cramped electrical boxes.
Dielectric Grade Insulation
PVC compound insulation prevents electrical leakage and withstands voltage spikes efficiently.
Thermal Overload Protection
Excellent thermal stability ensures insulation remains intact during sudden overload or peak operating loads.
High Chemical Resistance
Resistant to exposure to alkalis, mild acids, oil, and grease, allowing versatile use in industrial environments.
Technical Specifications & Parameters
Technical construction parameters and specifications for Flexible Wires and Twin Parallel Cables.
| Conductor Size / Code | No. / Nom. Dia of Strands (mm) | Nominal Insulation Thickness (mm) | Current Rating AC (Amps) | Max. Conductor Resistance @ 20°C (Ω/km) |
|---|---|---|---|---|
| 0.50 Sq. mm. | 16 / 0.20 | 0.6 | 4 A | 39.0 |
| 0.75 Sq. mm. | 24 / 0.20 | 0.6 | 7 A | 26.0 |
| 10 / 14 | 14 / 0.20 | 0.5 | 5 A | 35.0 |
| 18 / 23 | 23 / 0.18 | 0.5 | 7 A | 26.0 |
| 23 / 76 (Twin Parallel) | 23 / 0.193 | 0.6 | 6 A | 27.0 |
| 30 / 40 | 40 / 0.20 | 0.6 | 10 A | 18.0 |
| 40 / 76 (Twin Parallel) | 40 / 0.193 | 0.6 | 12 A | 14.5 |
